viii.
Vehicle information including Datalink status, ICU
serial number, software version
ix.
Outside air temperature
x.
Fasten seat belt warning
Trip Information
Trip Information displays the trip miles, trip adviso-
ries, idle hours, leg miles, and leg advisories, in that
order.
Fuel Information
Fuel information displays total fuel usage since the
last reset, fuel mileage, and fuel consumed while
idling or running the PTO, in that order.
Engine Information
Engine information displays engine mileage and
hours, and total fuel consumption, in that order.
Diagnostic Information
If active fault codes are displayed on the diagnostic
information screens, make a note of the fault code
and text message, then take the vehicle to an autho-
rized Freightliner service facility See
Fig. 4.17 for a
diagram of the diagnostic information screens.
Service Information
The Service Information menu displays the next ser-
vice interval, expressed in either miles or hours. See
Fig. 4.17. Service intervals can also be deactivated.
For programming service intervals, see Setup Infor-
mation, below.
NOTE: If the vehicle has exceeded the service
interval, the miles(km)/hours remaining screen
is replaced by the service was due screen, fol-
lowed by the number of miles(km)/hours since
the service was due.
IDLE HOURS 1234:56
12.3 GAL 123456.7 MI
R
RR
R
RR
R
+
+
+
−
−
−
− −
−
−
−
−
−
− − −
TRIP
INFORMATION
FUEL
INFORMATION
ENGINE
INFORMATION
TRIP MILES 123456.7
TRIP HR 1234:56
TRIP ADVISORIES
123 ROLL 456 BRK
IDLE HOURS 1234:56
AVG MPH 12.3
LEG MILES 123456.7
LEG HR 1234:56
LEG ADVISORIES
123 ROLL 456 BRK
FUEL USED 12345.6
AVG MPG 12:34
IDLE GALLONS 12345.6
PTO GAL 12345.6
ENG MILES 1234567.8
ENG HOUR 1234:56
ENG GALLONS 123456.7
PTO GAL 123456.7
OIL LVL
*Lo
f545600b
−
01/30/2012
−
85
ENGINE
PER
*Lo ENGINE
R
=
H
o
l
dto
r
e
s
et.
P
U
S
H
+
KEY
T
O
C
O
N
F
I
R
M
C
LEA
R
C
onf
i
r
mat
i
on
sc
r
een
w
ill
d
i
s
p
l
a
y
r
i
ght afte
r
the f
i
r
s
tho
l
d.
+
My Info
Odometer
To Diagnostic Information Screen
Fig. 4.16, ICU4M Idle Hours, Trip Information, Fuel Information, and Engine Information Screens
