Service Bulletin #RL0536-05
Technical Service Bulletin
Date: September 20, 2005
Product Model: RL500/550/800/850
Serial Range: IRL03010000 and onwards
Part Number: GEN0207A / GEN0208A
Countries Affected: All
Front Wheel Detent Change
A new front wheel detent was introduced in 2003. If the S/N is IRL03010000 and onwards, use
the new Front Wheel detent (GEN0207A) with two Front Wheel detent springs (GEN0208A) as
shown in Figure 2 below.
If you are servicing a Robomower with a S/N
IRL02340100 and older, use part number
GEN0118A, front wheel detent spring, as shown in Figure 1 below.
Figure 1 Figure 2
