1.1.2 Robomow bottom view
Note: Mower sides are determined by its top view
16
Snap lock (curved)
GEN0163A
(
x4
)
Snap lock (straight)
GEN0162A
(
x6
)
11
Front Wheel
SPP0011A
Front Bumper
MSB0106B
12
Mowing Motor
MSB0065B
(
x3
)
15
High cut blades
MRK0002A
Low cut blades
MRK0003A
14
5
Rear Bumper
MSB0107B
3
Knobby drive wheel
MSB0099A
13
10
RL plastic base
GEN0095A
Figure 1.1.2 Bottom view
1
3
