1.1.4 Charging Station views
5
30
Charging
Station Base
SPP0029A
Charging Station
contacts assembly
SPP0031A
32
Charging
Station Cover
SPP0030A
29
Charging
Station Drive
Wheel support
123
122
Charging
Station Fence
GEN0215B
31
Figure 1.1.4 Charging Station view
