7.4 TorqueMaster
As an alternave to standard clamping devices, the TorqueMaster can be
used f
or faster and more accurate clamping.
1 TorqueMaster clamping unit with toothed belt
2 Clamping lid
3 Hexagon socket bit (5.5)
4 Cordless screwdriver (with baery and charger)
5 Unclamping aid
NOTICE!
The unclamping aid included is t
o be used exclusively
for releasing a clamped sieve stack (in case of malfunc-
on of the cordless screwdriver). The unclamping aid
has no torque limitaon, and if it is used for clamping,
prevenon of operang errors and possible irreparable
damage to the clamping unit can therefore not be guar-
anteed.
7.4.1 Fing the TorqueMaster clamping device
The sieves are ed as described in
Ä Chapter 6.1.1 „Fing and
clamping the sieves“ on page 23. To clamp using the TorqueMaster pro-
ceed as follows:
1. The
starng posion of the clamping system is the posion at
which both indicators are roughly in the centre of the respecve
display range.
This posion later ensures that sieve stacks of various heights can
be clamped easily, or that there is sucient space to release the
system, remove it from the sieve stack and place it behind the
device.
