Froling FHG 20 - Package Contents; Before Installation

Boiler Installation
Boiler assembly
Page 20
M1060008_US v
3
3.3 Package contents
A
Boiler
B
Insulation
C
Heat-exchanger system
(optional)
D
Flue gas pipe nozzle
E
Ceramic fiber seal
F
Induced draught fan
G
Cardboard box containing
small parts
H
Rods for primary and
secondary air
I
Ash shovel
J
Cleaning kit
K
Cleaning brush, small
L
Cleaning brush, large
The following are also included in the package contents but not pictured:
Lambdatronic control unit, pressure relief valve, pressure/temperature
gauge, Honeywell overheat aquastat, installation instructions, operating
instructions, guarantee certificate, identification plate
3.4 Before installation
 IMPORTANT: The boiler doors are attached on the right hand side
when delivered. Carry out the following assembly steps if the doors
need to be attached on the left:
A
B
L
D
K
E
F
G
H
J
I
C
