Froling FHG 20 - Installing the Lambda Probe; Installing the Rear Insulation Covers

Boiler Installation
Boiler Assembly
Froling GmbH, Industriestrasse 12, A-4710 Grieskirchen, Austria Page 35
www.froling.com M1060008_US
3
Installing the lambda probe
 Unscrew the pre-installed bushing from the lambda probe
 Screw the bushing into the flue gas nozzle and tighten gently
 Screw the lambda probe into the bushing and tighten gently
 Never place a wrench or pliers on the cylindrical metal body
Installing the rear insulation covers
 Install the cabling
 See chapter 3.7 Electrical
connection
 Position the pieces of insulating wool
pad on the left and right of the flue
pipe nozzle
 Position the insulation covers
