Boiler Installation
Electrical connection
Page 40
M1060008_US v
3
Sensor of Door Switch
Sensors for Thermal Storage System
Feed through Door
Sensor Switch Wires
Connect Wires to
Connector
Plug in the Door
Switch Connector
Feed through Sensor
Wires
Connect Wires to
Connector
Plug in Sensor 1
Connector
Plug in Sensor 2
Connector
