5.4 Menu Overview
 See 5.5 Menu - Storage tank
 See 5.6 Menu – Boiler
 See 5.7 Menu – Manual
 See 5.8 Menu - System
5.5 Menu - Storage tank
5.5.1 Status display of the Thermal Storage System
Storage tank
01 ... 08
Display
Description
Storage tank top
temperature 55°C*
Current temperature at Thermal Storage System top sensor.
Storage tank bottom
temperature 50°C*
Current temperature at Thermal Storage System bottom sensor.
Storage tank pump control 0%
Function not used! Pump control either 0% or 100% speed!
Specifies the speed of the Thermal Storage System circulator as a
percentage of maximum speed.
*Verify sensor readings.
