Slide the complete side insulation assembly
towards the rear until the black, perforated L
plates meet the front face of the boiler body.
Recommendation: Install the cleaning port
door on same side as the cleaning lever.
Install the cleaning port door using 3 Allen
screws. Start with the large threaded boss.
Attach the door handle for the cleaning port
door using a round headed screw
Install the blank cover for the side cleaning
port on the required side
When complete, the handle must latch with a
downward motion.
