For the fuel loading chamber door:
Position the door handle in the hole
provided
Insert flange bushing into door
handle
Fasten the door handle in place
Repeat the above steps for the pre-
heating chamber door and the
combustion chamber door
Fitting the door for closure is
accomplished by pressing the door
closed until the gasket makes
contact on the hinge side. Tighten
the hinge side bolts. Re-tighten
latch bolts after the door is
mounted
