Froling FHG 20 - System Parameters; Boiler Type - Do Not Change

Boiler Control System Lambdatronic S 3200
Froling GmbH, Industriestrasse 12, A-4710 Grieskirchen, Austria Page 61
www.froling.com M1060008_US
5
5.8.6 System parameters
 For changing the current
system parameters
Boiler type – Do not change!
..
.
Boiler type
-
S4 Turbo 15
Lambda probe installed YES
S4 Turbo 22/28
Servo-motors installed YES
S4 Turbo 34/40
Ignition installed *) NO
S4 Turbo 50/60
Return feed lift pump
Installed * NO
FHG Turbo 3000 20 Selected
-
FHG Turbo 3000 30
Return feed mixer installed *) NO
FHG Turbo 3000 40
FHG Turbo 3000 50
FHG Turbo 3000 70
Do not select
S4 Turbo,
FHG Turbo 3000 70,
Pellet boilers P2,
Pellet boilers P4 or
Turbomatic
Pellet boiler P2 - 10
:
Pellet boiler P2 - 25
Pellet boiler P4 - 15
:
Pellet boiler P4 - 38
Turbomatic
Turbomatic 28...55
Turbomatic 70...110
Wood boiler F2 22 / 30
* All marked components not used! Adjust parameter to NO!
