3.7.3 Connecting sensors
Flue Gas Sensor
Lambda Probe
Feed through Lambda
Probe Wires
Feed Wires through
Wire Knockout
Plug in Broadband
Probe Connector
Feed through Flue Gas
Sensor Wires
Connect Wires to
Connector
Plug in Flue Sensor
Connector
