2 | Power connection and wiring
26 B1820023_en | Service handbook Lambdatronic H 3200 - T4e
NOTICE!The inputs and output are pre-configured, so it is essential the following addressing is
complied with.
Standard configuration – Digital module with address 1
Input Designation
1 T4e 300 - 350
SSM pumps
5
Tilt motor 3 open
6
Tilt motor 3 closed
7
Tilt motor 2 open
8
Tilt motor 2 closed
Output Designation
1
Open tilt motor 2
2
Close tilt motor 2
3
Open tilt motor 3
4
Close tilt motor 3
5
Primary air flap open
6
Primary air flap closed
Standard configuration – Digital module with address 3
Input Designation
1
Hydraulic pump motor protection switch
2
Hydraulic oil level sensor
3
Hydraulic oil temperature
4
Hydraulic chamber key switch
5
Safety limit switch
6
Light scanner 1
8
Light scanner 2
Output Designation
1
Sliding floor on
2
Star-delta start-up 1
3
Star-delta start-up 2
Standard configuration – Digital module with freely selectable address (discharge
configurator)
Input Designation
1
Overcurrent screw 1
2
Light barrier 1
3
Motor protection switch screw 1
4
Overcurrent screw 2
5
Light barrier 2
6
Motor protection switch screw 2
