Parameters overview | 4
B1820023_en | Service handbook Lambdatronic H 3200 - T4e 81
Electrostatic separator operating hours
Shows the operation hours since the electrostatic
separator was first activated.
Number of cleaning processes
Shows the total number of cleaning processes since the
electrostatic separator was first activated.
Number of flashovers
Shows the total number of flashovers since the
electrostatic separator was first activated.
Absorbed energy
Shows the total amount of absorbed energy since the
electrostatic separator was first activated.
Power HV module 1
Actual output of the HV module in W.
Output level HV module 1 … 4
Displays the current output of the respective HV module
as a numeric code. The following displays are possible:
▪ Output “0”: The current output of the HV module is
between 0 - 25%
▪ Output “1”: The current output of the HV module is
between 25 - 50%
▪ Output “2”: The current output of the HV module is
between 50 - 75%
▪ Output “3”: The current output of the HV module is
above 75%
Feedback HV module 1 ... 2
Displays the feedback from the respective HV module:
▪ Off
▪ Start
▪ Normal operation
▪ Excessive temperature HV box
▪ Error
▪ Restart
Service
Enable electrostatic separation function
Used to activate/deactivate the electrostatic separator’s
function.
Number of HV modules
Specifies the number of HV modules used. One or two
modules are used, depending on the output of the boiler.
Max. output of HV modules
This is used to set the output power of the HV module in
Watts. If two modules are used, the output of one module
must be set here. If more than one module is used, HV
modules with the same output power should always be
used.
Startup criteria for HV modules - flue gas
temperature
If the flue gas temperature of the boiler exceeds the set
value, the HV modules are switched on. If the flue gas
temperature falls below the set value during heating
mode, the HV modules remain switched on.
HV cleaning system
Defines the type of cleaning system for the HV electrode
of the e-filter. Cleaning takes place either by means of
vibrator or air flush.
Number of cleaning cycles per heating hour
Determines the number of cleaning processes per boiler
operating hour in heating mode. Together with the
cleaning duration (parameter “Duration of cleaning cycle”),
the total cleaning time is calculated.
Example: Number of cleaning cycles per heating hour = 3,
duration of cleaning cycle = 3s, heating hours until
cleaning = 4 h,
Results in a cleaning time of 36 seconds (4 x 3 x 3)
Duration of cleaning cycle
Defines the total time for a cleaning process. During this
time the shaker is switched on.
Cleaning active during heating
▪ YES: When the time for cleaning is reached (parameter
“Cleaning interval”) and no blocking window is active
(menu System => Set => Cleaning), the HV modules
are switched off in heating mode. After a pause of 15
seconds the electrode is cleaned and after a further
pause of 15 seconds the HV modules are switched on
again.
IMPORTANT: For the cleaning after switching off the
boiler, the cleaning in heating mode is taken into
account!
Example: Cleaning interval = 5 h; cleaning is carried
out after 5 h heating mode. If the boiler switches off in a
controlled manner after 7 h, the cleaning time of the
electrode is only calculated for the 2 h in heating.
▪ NO: The electrode is cleaned only after the boiler has
been switched off.
