IO allocation
Setting of the relevant address for the respective
component for the inputs and outputs on the digital
module.
▪ Address HV in 1
▪ Address HV in 2
▪ Address water sensor 1
▪ Address water sensor 2
▪ Safety switch address
▪ Address HV out 1
▪ Address HV out 2
▪ Address bypass flap open
▪ Address washer valve 1
▪ Address washer valve 2
Internal elec. sep.
Setting
Flue gas Internal elec. sep.
State
Electrostatic separator status
Displays the current operating status of the electrostatic
separator as a numeric code. The following statuses are
possible:
▪ Status “0”: Separator deactivated
▪ Status “1”: Separator OFF
▪ Status “2”: Separator ON
▪ Status “3”: Measuring mode
▪ Status “4”: RFI
▪ Status “5”: Wait for bypass flap
▪ Status “6”: Cleaning - Pause
▪ Status “7”: Cleaning - Rinse
▪ Status “8”: Wait for water sensor
▪ Status “9”: Waiting for drying time
▪ Status “10”: Separator error
▪ Status “11”: Quick cleaning
▪ Status “12”: Waiting for drying time
▪ Status “13”: Cleaning – Waiting
▪ Status “14”: Cleaning – Shaking
▪ Status “15”: Cleaning – Waiting
Electrostatic separator return signal
Shows the status of the electrostatic separator as a
numeric code. Following status values are possible:
▪ Status "0": No error
▪ Status "1": Power supply fault
▪ Status "2": RS485 error
▪ Status "3": Temperature box error
▪ Status "4": High voltage error
▪ Status "5": Wait for ready-to-measure state
▪ Status "6": Values critical
▪ Status "7": Measure
▪ Status "8": Measuring mode error
Voltage feedback HV module 1
Actual voltage of the HV modules in kV.
Current feedback HV module 1
Actual current of the HV module in mA.
Time until next cleaning
Shows the remaining time (in minutes) until the next
cleaning process.
