Maximum speed of the circulation pump
If for system operation reasons you need to limit the
maximum speed of the circulation pump you can do so by
adjusting this parameter.
4.13 Manual
4.13.1 Manual - Manual operation
System menu Manual
Manual operation
When exiting the “Manual operation” menu, all active parameters are automatically set to “OFF”! The
parameters displayed depend on the boiler configuration!
Stoker ON
▪ ON: The stoker screw drive is activated.
Feed screw ON
▪ ON: The feed screw drive is activated.
Suction screw of cyclone 1 … 2
▪ ON: The drive of the suction screw at cyclone 1 is
activated.
Bunker filling rotary agitator
▪ ON: In the case of rotary agitator with a separate drive
system, the head of the rotary agitator is operated
separately from the delivery screw.
Ignition
▪ ON: The hot air blower / ignition rod for igniting the fuel
is activated.
Oufeeder - manual
▪ ON: The stoker and feed screw drive is activated.
Ash screw
▪ ON: The ash screw drive is activated.
Rinse the condenser manually – only possible if boiler
off / on standby
▪ ON: The solenoid opens and the calorific value heat
exchanger is cleaned.
NOTICE!This parameter can only be activated when
the boiler is in “Standby” or “Boiler off” status.
Clean electrostatic separator manually- only while the
boiler is off / in standby mode
The cleaning of the electrostatic precipitator can be
started manually.
Grate drive
The grate drive manual controls can be used to move it
back and forth, and also to switch it off.
Suction screw for the active suction zone
If a 1-2-3 suction module is used, the suction screw for the
suction zone that is currently active is manually controlled.
