Sensor input of distributor 1 return sensor
Prerequisite: Variant 1 and pump for distributor 1
installed
Sensor input to which the sensor for the return distributor
1 is connected.
Pump output of distributor 1 pump
Prerequisite: Variant 1 and pump for distributor 1
installed
Pump outlet to which the pump for distributor 1 is
connected.
Control of distributor 1 pump
Prerequisite: Variant 1 and pump for distributor 1
installed
Definition of control signal for pump type used.
Ü "Activation options of pump outlets" [}96]
Minimum speed for distributor 1 pump
Prerequisite: Variant 1 and pump for distributor 1
installed
Adjustment of the minimum speed to the pump type (set
mode of pump in accordance with pump manufacturer).
Maximum speed for distributor 1 pump
Prerequisite: Variant 1 and pump for distributor 1
installed
If for system operation reasons you need to limit the
maximum speed of the distributor 1 pump you can do so
by adjusting this parameter.
Sensor input of distributor 2 ... 4 return sensor
Prerequisite: Variant 2 or variant 3 and pump for
distributor 2 ... 4 installed
Sensor input to which the sensor for the distributor 2 ... 4
return is connected.
Pump outlet of distributor 2 ... 4 pump
Prerequisite: Variant 2 or variant 3 and pump for
distributor 2 ... 4 installed
Pump outlet to which the pump for distributor 2 ... 4 is
connected.
Activation of distributor 2 ... 4 pump
Prerequisite: Variant 2 or variant 3 and pump for
distributor 2 ... 4 installed
Definition of control signal for pump type used.
Ü "Activation options of pump outlets" [}96]
Minimum speed for distributor 2 ... 4 pump
Prerequisite: Variant 2 or variant 3 and pump for
distributor 2 ... 4 installed
Adjustment of the minimum speed to the pump type (set
mode of pump in accordance with pump manufacturer).
Maximum speed for distributor 2 ... 4 pump
Prerequisite: Variant 2 or variant 3 and pump for
distributor 2 ... 4 installed
If for system operation reasons you need to limit the
maximum speed of distributors 2 ... 4 pump you can do so
by adjusting this parameter.
4.10 Cascade
4.10.1 Cascade - Status
System menu Cascade
Buffer tank charge
Display of the current buffer tank charge.
