Froling T4e - 4.9 Network pump; 4.9.1 Network pump - Status

Parameters overview | 4
B1820023_en | Service handbook Lambdatronic H 3200 - T4e 65
Minimum current monitoring active
▪ YES: A failure of measured phase is detected.
Service hours of suction screw
Prerequisite: Large-scale suction system with one
cyclone and 2 rotary valves.
operating hours of suction screw discharge on a GASS.
Suction turbine operating hours
Counter for the operating hours of the suction turbine.
Preliminary suction time
Time before the discharge screw starts.
Suction zone 1 … 3 activated
A suction zone can be activated or deactivated.
Deactivated suction zones are skipped when changing the
suction zones.
Screw cycle
Discharge screw runtime, minus an adjustable pause
time.
Screw at address
Address at which the screw has been connected.
Pellet mole run-on, applies after the MAX sensor
triggered
The pellet mole remains activated for the set time when
the cyclone is full.
Pellet mole cycle
Total time of a pellet mole's cycle.
Maximum number of suction cycles before changing
over the probe
Defines the number of suction cycles before changing
over the probe, in order to achieve balanced emptying of
the storage room.
Addressing
Specifies to which module the respective suction screw is
connected.
Operation hours of pellet mole
Specifies the operating hours of the pellet mole.
Nominal current of the suction screw
Specifies the nominal current of the suction screw motor
according to the identification plate on the motor.
Controlling the suction zones
Suction zones can be activated individually.
4.9 Network pump
4.9.1 Network pump - Status
System menu Network pump
Network return temperature
Display of the current return temperature of the remote
line.
Network pump speed
Specifies the current speed of the network pump.
Return temperature distributor 1
Prerequisite: Variant 1 and feeder pump for distributor 1
installed
Display of the current return temperature from distributor
1.
Speed, distributor 1 pump
Prerequisite: Variant 1 and pump for distributor 1
installed
Display of the current speed of distributor 1 pump.
Return temperature distributor 2 … 4
Prerequisite: Variant 2 or variant 3 and pump for
distributor 2 ... 4 installed
Display of the current return temperature from distributor
2 ...4.
