2 | Power connection and wiring
28 B1820023_en | Service handbook Lambdatronic H 3200 - T4e
Connection / Name Note
AU-10 Gravity shaft cover 2
Connection cable
1)
2 x 0-76mm
2
AU-11 Gravity shaft cover 1
AU-12 Input latch
AU-13 External release
AU-14 Mains
Connection cable
1)
5 x 2.5 mm
2
AU-15 Combi drive T4e 80-180
Connecting cable
1)
4 x 1.5 mm
2
; max. 0.75 kW / 400 V
(e.g. connecting a feed screw)
Feed screw T4e
200-350
AU-16 Output 1
AU-17
:
AU-22
F1
:
F6
3.15 AT fuses
1. YMM to ÖVE-K41-5 or H05VV-F to DIN VDE 0881-5
Fuses
F1, F3, F4 3.15 AT
AU-15
F2, F5, F6 3.15 AT
AU-16
