Cumulative Error
- Signal in the event of an error
- A power failure can be displayed as an error ("ON" setting).
- If the device is in an error state, a freely defined text can be displayed, which can
contain the contact details of the dealer, for example. Detailed information can be
found in the "USB mode" section.
Cumulative error + warning
- In the same way as the "Cumulative Error" function, the corresponding relay picks
up as soon as an error or warning is present.
Signal Lamp
- It is possible to connect one or more suitable lamps to the relay board to indicate the
state of charge or the operating status of the battery charger.
- Detailed information can be found in the "Signal lamp" section of the "Options"
chapter.
Immobiliser
ON
- The relay picks up continuously as soon as the battery charger is connected to the
grid.
Refill Indicator
- Indicates that it is necessary to refill the battery with distilled water.
- Detailed information can be found in the "Additional functions" section of the "Dis-
play" chapter.
Battery Cold
External Air Pump
- The settings are made as explained in section "-> Settings" for "Air Pump".
Detailed information on the relay board can be found in the "Options" chapter.
External lamp
According to the "Charging lights" section of the "Options" chapter, suitable external in-
dicators can be connected in order to visualize the state of charge or the operating status
of the battery charger. The following settings are available:
- Normal (conventional external indicators)
- RGB (LED strips)
Remote control system
The contrast for the remote control system can be adjusted.
at mains failure restart charging
If this option is activated, the charging process is automatically restarted after a fault in
the electrical network as soon as the electrical network is available again.
46
