Technical data
Selectiva 8 kW
400 V
WARNING!
An electric shock due to a residual current can be fatal.
Only use a type B residual current circuit breaker for the grid connection of the device.
Mains voltage (-10% / +30%)
1
)
Optional:
3~ NPE 400 V / 50/60 Hz
3~ PE 400 V / 50/60 Hz
Mains fuse
2)
16 A
Minimum cross-section of the grid lead 2.5 mm² (0.003875 in.²)
Duty cycle 100%
EMC device class B
Standby consumption
24 V devices
48 V devices
80 V devices
10 W
10.1 W
10.3 W
Safety class I
Max. permitted grid impedance Z
max
on PCC
3)
None
Degree of protection
4)
IP 20
Overvoltage category III
Operating temperature
5)
-20°C to +40°C
(-4°F to 104°F)
Storage temperature -25°C to +80°C
(-13°F to 176°F)
Relative humidity Max. 85%
Maximum altitude above sea level 2000 m (6561 ft.)
Mark of conformity According to rating plate
Product standard EN 62477-1
Dimensions L x W x H 633 x 180 x 344 mm
(24.92 x 7.09 x 13.54 in.)
Weight (with standard grid and charging cable) 23 kg (50.71 lb.)
Pollution degree 3
1) The device may be operated on grids that are grounded at the neutral point with
a maximum outer conductor nominal voltage of 400 V. A mains voltage tolerance
L-N of 207 V to 250 V applies to the electrolyte circulation and relay board op-
tions.
2) Only use a type B residual current circuit breaker for the grid connection of the
device.
If the device is fused with 32 A, the thermal rating of the automatic circuit breaker
must not exceed 82,000 A²s.
The leakage current to ground is less than 3.5 mA.
3) Interface to a 230/400 V and 50 Hz public grid.
