67
EN
Factory settings OFF
"ON" The pulsed welding current continues until the end of the tack-
ing operation
0.1 - 9.9 s The set time begins with the upslope phase. After the end of the
set time, welding continues at a constant current; any pulsing
parameters that have been set are available.
"OFF" The tacking function is switched off
The special tacking indicator on the control panel remains lit as long as a value has been
specified for the tacking time.
F-P
Frequency pulsing
Unit Hz / kHz.
Setting range OFF / 0.20 Hz - 2.00 kHz
Factory settings OFF
The set pulse frequency is also used for the reduced current I2.
IMPORTANT! If F-P is set to "OFF", the dcY and I-G setup parameters cannot be select-
ed.
The special pulsing indicator on the control panel remains lit as long as a value has been
specified for the pulse frequency.
Selecting the pulse frequency F-P:
0.2 Hz to 5 Hz Thermal pulsing (out-of-position welding, automated welding)
1 kHz to 2 kHz Arc-stabilising pulsing (stabilising the arc at a low welding cur-
rent)
dcY
Duty cycle - the ratio of pulse duration to the ground current duration when a pulse fre-
quency has been set
Unit %
Setting range 10 - 90
Factory settings 50
I-G
I (current) - ground current
Unit % (of main current I1)
Setting range 0 - 100
Factory settings 50
