MASTER JET CF SERIES ATMOSPHERIC GAS FRYERS
CHAPTER 1: SERVICE PROCEDURES
1-36
1.12.2 MJCF Millivolt Wiring Diagram, CE
FENWALL
OPERATING
THERMOSTAT
8050531A
PILOT GENERATOR
(THERMOCOUPLE)
MAIN VALVE/COIL
GENERATOR
(THERMOPILE)
HIGH-LIMIT
THERMOSTAT
