MASTER JET CF SERIES ATMOSPHERIC GAS FRYERS
CHAPTER 2: PARTS LIST
2-27
2.7.8.2 Euro-Look Drain Valves and Related Components-Round Drains
ITEM
EURO-LOOK
PART # **
COMPONENT
106-3760 Valve, Drain Assembly Full Vat
1 200-6496 Support, Drain 3” Tube
2 824-1602 Handle, Drain Valve FV
3 806-8137 Bracket, Switch, Drain, Assembly
4 807-2103 Switch, CE Micro Straight Lever
5 809-0237 Nut, 4-40 KEPS Hex w/ Ext Tooth
6 809-0540 Nut, 2-Way Lock ½”-13 ZN PL
7 810-1018 Valve, 1-1/4” FPD – TCF w/out Handle
8 816-0639 Sleeve, Handle Valve Red w/ Logo
9 816-0135 O-Ring, Round Drain
10 816-0220 Insulation, RF Switch
11 901-2348 Cover, DV Safety Switch
12 900-2936 Retainer, Nut Drain Valve
13 810-1165 Washer, Teflon Drain Valve
** See page 2-26 for a Standard parts list.
