MASTER JET CF SERIES ATMOSPHERIC GAS FRYERS
CHAPTER 2: PARTS LIST
2-4
2.2 Burner Manifold Components (cont.)
ITEM
STANDARD
PART #
EURO-LOOK
PART #
COMPONENT
5
Pilot Assembly
810-2071 Natural Gas, w/Thermopile (use 810-0426 for pilot only)
806-8688SP Natural Gas, w/Thermocouple (CE)
810-2070 Propane (LP), w/Thermopile (use 810-0427 for pilot only)
806-8689SP Propane (LP) Gas, w/Thermocouple (CE)
810-1831 Manufactured Gas, w/Thermocouple (CE and non-CE)
806-6825SP Dual Pilot, Natural Gas (CE)
806-6827SP Dual Pilot, Propane (LP) Gas (CE)
6 823-0330 Shield, Burner- All MJCF Series
* 930-3472 Shield, Heat, Lower Right Front
* 930-3471 Shield, Heat, Lower Left Front
7 810-1873 Thermopile with Push-on Terminals (Used in Non-CE Pilot Assemblies)
8 812-1284
Thermocouple with Threaded Terminal- 29-½" (Used in CE Pilot
Assemblies)
* 807-0699
Thermocouple with Threaded Terminal- 20" (Used in England/Germany
Pilot Assemblies)
9 810-0705 Gas Line, Pilot Supply- ¼ x 23"
* 810-2484 Gas Line, Pilot Supply- ¼ x 10"
* 810-1700 Gas Line, Pilot Supply- ¼ x 8-¾" (Series J65X Only)
10 810-0691 Vent Tube, Gas Valve
11
Valve, Gas- Non-CE Only
807-3294 24V Only- Natural & Manufactured Gas (Honeywell)
807-3295 24V Only- Propane/Butane Gas (Honeywell)
807-1603 Millivolt Only- Natural & Manufactured Gas (Honeywell)
807-1604 Millivolt Only- Propane Gas (Honeywell)
12
Valve, Gas- CE Only
806-6840SP 24V Only- Natural and Manufactured Gas (Honeywell)
807-2127 24V Only- Propane Gas (Honeywell)
806-6805SP Millivolt Only- Natural Gas (Honeywell)
807-2121 Millivolt Only- Propane Gas (Honeywell)
* 806-4781 Capacitor (Used on Gas Valve Terminals w/Thermostat Cont. Only)
* 810-1307 Valve, Gas Supply Turn-off (Inside Fryer Cabinet)
*
Miscellaneous Components – Older Production Units
* 810-0187 Regulator, Natural Gas (Robertshaw)
* 817-0098 Regulator, Propane Gas (Robertshaw)
* 806-1452SP Valve, Gas- 120V Natural (Robertshaw)
* 806-1986SP Valve, Gas- 120V Propane (Robertshaw)
* Not illustrated.
Use standard part.
