MASTER JET CF SERIES ATMOSPHERIC GAS FRYERS
CHAPTER 2: PARTS LIST
2-6
2.3.1 Fryer Cabinetry (cont.)
ITEM
STANDARD
PART #
EURO-LOOK
PART #
COMPONENT
3 900-7367SP 201-6916 Side, Left & Right - MJCF CRS Cabinet (Euro Left Side Only)
202-6916 Side, Right MJCF CRS Cabinet Euro
* 910-7367SP 211-8427 Side, Left & Right - MJCF S/S Cabinet (Euro Left Side Only)
212-8427 Side, Right - MJCF S/S Cabinet
4 900-4401 200-6758 Brace, Cabinet- Lower Front
5 900-4428SP Brace, Cabinet- Upper Front & Rear
6 900-1714 930-0411 Spacer, Flue Cap
7 900-5541 200-6742 Base, MJCF/FMCF/Spreader Cabinet- One-Piece
8 900-9316 200-6732 Back, Cabinet- MJCF/FMCF, CRS
* 910-9316SP 210-6732 Back, Cabinet- MJCF/FMCF, S/S
9 816-0128 Insulation, Cabinet- Upper Rear
10 816-0127 Insulation, Cabinet- Lower Rear
11 900-4419 Retainer, Insulation- Upper and Lower Back
12 823-2150 823-4710 Fluecap, MJCF/FMCF
13 824-0491 824-1318 Topcap, Single – MJCF/FMCF
* 824-0492 824-1373 Topcap, Dual – MJCF/FMCF
* 824-0493 824-1434 Topcap, Triple – MJCF/FMCF
* 824-0494 824-1449 Topcap, Quad – MJCF/FMCF
14 810-1422 210-6764 Handle, Door- Wireform
15 824-0118SP Panel, Door- MJCF/FMCF, CRS
* 824-0770SP 824-1326 Panel, Door- MJCF/FMCF, S/S
16 930-6604 200-6762 Liner, Door- All MJCF/FMCF
17 806-4487SP Pin Assembly, Door- All MJCF/FMCF
18 810-1508 Hinge, Door- All MJCF/FMCF
* 823-4713 Hinge, Door Lower Euro-Look
* 823-4715 Hinge, Door Upper Euro-Look
* 809-0449 Screw, #10 x ½ Phip TR HD NP
19 810-1105 Magnet, Door- All MJCF/FMCF
20 900-1390 Brace, Frypot to Cabinet- MJCF/FMCF
* 106-3931 Door Assembly, CF Euro-Look
* 106-4035 Cabinet Assembly MJCF Single Euro-Look CRS
* 106-4029 Cabinet Assembly MJCF Single Euro-Look S/S
* 809-0535 T-Nut, Fluecap (round hole)
* 809-0015 Cagenut, Fluecap (square hole)
* Not illustrated.
Use standard part.
