MASTER JET CF SERIES ATMOSPHERIC GAS FRYERS
CHAPTER 2: PARTS LIST
2-14
2.6 Control Panel Assemblies and Related Components (cont.)
ITEM
STANDARD
PART #
EURO-LOOK
PART #
COMPONENT
1 806-4992SP 106-4055 Frame Assembly, Control Panel
* 809-0448 Clip, Tinnerman (Control Panel Screw)
2 806-0183 106-0771 Thermostat, Operating (Non-CE)
* 806-9617 806-9708 Thermostat, Operating (CE Only)
3 809-0157 Screw, Set- 8-32 x 3/8"
4 810-1000 810-2954 Shaft, Flex- Thermostat Control
5 809-0050 Nut, Hex
6 826-1361 Screw, Stop (Qty: 25)
7 810-0624 810-2862 Adapter, Shaft End
* 900-2071 Bracket, Shaft Guide- Thermostat Shaft
* 900-2241 200-8536 Bracket, Thermostat
8 810-0334 Knob, Thermostat
9 910-7287 210-8702 Panel, Control- MJCF With Timers- Millivolt Only
* 910-7280 210-8699 Panel, Control- MJCFE With Timers
10 810-0585 Timer, 15-Minute Mechanical
11 802-1473 Label, Dial- 15-Minute Mechanical Timer
* 910-1551 Bezel, 15-Minute Mechanical Timer
12 810-1287 Knob, 15-Minute Timer
13 910-7288 210-8698 Panel, Control- MJCF, Millivolt Only (Older units use 910-7282)
* 806-0831SP Switch, Toggle- MJCF, Millivolt Only (Older Production Units)
14 802-1470 Label, Dial Plate- Thermostat Knob
15 826-1395 Button, Plug- Thermostat Knob Shaft (Qty: 10)
* 826-1338 Bushing, Heyco- Shaft Button Plug (Qty: 25)
16 910-7281 210-8701 Panel, Control- MJCFE, With Timers
17 802-0765 Label, On/Off, Light, Melt Cycle Option- MJCFE
18 807-3498 Switch, Rocker, Melt Cycle I/O, w/24V Lamp, Amber
* 807-0496 Switch, Rocker Momentary on/off switch
* 807-3575 Hole Plug, Switch (MJCFE Without Melt Cycle Option)
19 807-3498 Switch, On/Off (Power)
* 826-1792 Switch Kit, On/Off (Power)/Melt-Cycle (To Replace Old Switches)
20 807-1525 Light, 24V (White Lens)
21 823-1800 210-6777 Panel, Control- MJCFEC (For Computers)
* 210-6766 Panel, Control Euro-Look Single Non-Computer
22 910-7289 Panel, Filter- FMCF Filter Magic II Cabinet
23 807-1275 Light, Ready Indicator- 2V
24 106-1177 106-4168 Computer, CMIII.5- MJCFEC (Non-CE)
* 106-1202 106-4169 Computer, CMIII.5- MJCFEC (CE)
* 106-6572 Controller, Digital - MJCFE
* Not illustrated. Use standard part.
