MASTER JET CF SERIES ATMOSPHERIC GAS FRYERS
CHAPTER 2: PARTS LIST
2-16
2.7.1.1 Filter Magic Drain Manifold Components (cont.)
ITEM
STANDARD
PART # **
COMPONENT
1 900-0757 Cover, Drain End, Square Drain- FMCF
2 816-0032 Gasket, Flange, Square Drain- FMCF
3 823-0717 Tube, Square Drain- 2-½ x 15.38"- FMCF
* 826-0715SP Drain Tube Kit (Gaskets, Clamps, Connecting Hardware, Clean-Out Cover)
4 823-0719 Elbow, Square Drain- FMCF
* 826-0716SP Sq Drain Elbow Kit (Elbow, Gaskets, Clamps, Connecting Hardware)
806-4068SP Elbow, Swivel, Complete Assembly (Items 5-9)- FMCF
5 823-1091 Tube Assembly
6 816-0083 O-Ring, Swivel Collar
7 809-0115 Screw, Retainer- 10-32 x ¼" Slotted Head
8 823-1092 Collar, Swivel Drain
9 810-0388 Knob, Clamping- Swivel Drain Collar
10 823-0714 Tube, Square Drain- 2-½ x 5.22"- FMCF Spreader Cabinet Option
11 816-0021 Gasket, Drain Cleanout – FMCF
12 826-1348 Cover, Drain Cleanout – FMCF (Qty: 5)
13 826-1382 Nut, Wing- 8-32 (Qty: 10)
14 823-0718 Tube, Square Drain- 2-½ x 8" – FMCF
15 810-0396 Clamp, Square Drain Flange – FMCF
* 826-0877 Clamp Kit – FMCF
16 826-1376 Nut, Keps- 10-32 (Drain Flange Clamp – Qty: 10)
17 826-1369 Screw, 10-32 x ½" Hex Head (Qty: 10)
18 809-0347 Nut, Drain Retainer (Conduit Nut)
19 826-1345 Washer Retainer, Drain Retainer Nut (Qty: 25)
20 816-0092 Grommet, Drain Retainer- 1"
21 813-0284 Nipple, Straight With Taper- 1 x ¾" NPT BM
* Not illustrated. ** See page 2-17 for a Euro-Look parts list.
