MASTER JET CF SERIES ATMOSPHERIC GAS FRYERS
CHAPTER 2: PARTS LIST
2-20
2.7.3 Filter Magic Filter Pan Components – Inner Pan Components (cont.)
ITEM
STANDARD
PART #
EURO-LOOK
PART #
COMPONENT
* 806-6095SP
FMCF Complete Filter Pan Assembly – Inner & Outer Pan
Assembly (Crumb Screen Not Included – Order Item #8 Below)
1 823-1745SP
Pan, Inner- FMCF
* 806-4866SP
Pan Assembly, Inner- FMCF (Crumb Screen Not Included)
2 816-0117
O-ring, Inner Pan Connection
3 809-0045
Nut, Cap- 10-32
4 910-1366
Handle, Filter Pan, Back (Nearest End With Hole In Pan Bottom)
5 810-0180
Handle, Filter Pan, Front (Nearest Door On Filter Cabinet)
6 823-2010
Screen, Filter Paper Support
7 810-1409
Ring, Hold-Down- FMCF
* 803-0171
Paper, Filter (100 Sheets) 33-¼ x 21"
* 803-0002
Powder, Filter (100 1-Cup Applications)
8 824-0417
Screen Assembly, Crumb- FMCF
* Not illustrated. Use standard part.
