MASTER JET CF SERIES ATMOSPHERIC GAS FRYERS
CHAPTER 2: PARTS LIST
2-30
2.8 Frypot, High-Limit and Probe Components (cont.)
ITEM
STANDARD
PART #
EURO-LOOK
PART #
COMPONENT
* 813-0408
Plug, Frypot – ¼" NPT BM
* 813-0156
Plug, Frypot – ½" NPT BM
* 813-0684
Plug, Frypot – 3/8" NPT BM
2 900-1090
Cover, Pilot
823-5302
Cover/Door, Pilot for Piezo Ignitor
3 810-0647
Holder, Pilot Cover Screw
4 809-0409
Screw, #10 x ½" Round-Head, One-Way
5 930-6401 806-0832 Chamber, Front Combustion (Order Insulation Kit Separately)
6 900-6412
Chamber, Side Combustion (Order Insulation Kit Separately)
7 823-0290
Channel, Frypot Rear (Order Insulation Kit Separately)
8 806-0833
Chamber, Rear Combustion (Includes Insulation)
9 806-0489
Flue, Front FMCF, MJCF with ¼ x12 x14½ Kaowool insulation
* 806-6978 Flue, Front MJCF CE
10 930-6386
Flue, Rear
11 806-4206 Probe, Assembly- Minco
12 210-0681
Guard, Probe
13 806-7550
Thermostat Assembly, High-Limit/ECO Connector (CE Only)
* 812-1256SP
ECO Connector Only [Requires soldering to high-limit wires and
the installation of wire nuts (14 AWG)]
14 826-1177 806-9708 Thermostat Assembly, High-Limit- 425°F
15 812-0211 Kaowool Blanket ½ x 7½ x 17½
* Not illustrated.
Use standard part.
