MASTER JET CF SERIES ATMOSPHERIC GAS FRYERS
APPENDIX
A-9
A.2 KJ3FC Variant – Parts List (cont.)
ITEM
STANDARD
PART #
EURO-LOOK
PART #
COMPONENT
1 900-4340
Shield, Component
2 900-1739
Brace, Component Shield
3 900-1635
Bracket, Component Shield
4 807-0276
Block, Terminal – 12-Pin
5 807-0800
Transformer- 120V/24V 50/60 Hz 50VA
* 807-0680
Transformer- 208/240V/24V 50/60 Hz 43VA
6 807-0855
Transformer- 120V/12V 50/60 Hz 20VA (KFC-1 Computers Only)
* 807-0979
Transformer- 208/240V/12V 50/60 Hz 20VA (KFC-1 Computers
Only)
7 807-0067
Block, Terminal – 8-Pin
8 824-0161
Support, Interface Board
9 806-5517
Board, Interface – Fast-Ready Computers Only
* 806-3548
Board, Interface – KFC-1 Computers Only
10 809-0096
Screw, 6-32 x 5/8" Slotted
11 809-0349
Spacer, 4 x 6 mm Aluminum
12 809-0250
Nut, Keps – 6-32
13 806-1076SP 806-5320 Switch Assembly, Pressure (Includes Items #14, 15 & 16)
14 809-0476
Nut, Jam – ½-20 (Two Required)
15 900-1749
Plate, Adapter – Pressure Switch
16 813-0389
Tee, Hex- ¾" (7/16 x 1/8 x 7/16)
17 807-3520
Speaker, Computer Sound – 4-Watt
18 910-7284 210-9552 Panel, Control – Fast-Ready Computer
* 823-1856 106-4082 Panel, Control – KFC-1 Computer
* 806-5162 106-4995 Frame, Control Panel – KFC-1 Computer
* 806-5300
Computer, KFC-1 – Gas
* 826-1507
Kit, Computer Conversion (Fast to KFC-1)
19 807-2196 807-3498 Switch, On/Off – Lighted Green
20 807-1547
Light, Indicator (Trouble) Red, 24V
21 807-1502
Light, Indicator (Heating) Amber, 24V
22 806-5045SP
Switch, Float Safety – Frypot Oil-Level
23 807-1524
Probe, Temperature – Fast-Ready Computer Only
806-6353SP
Valve, Drain Assembly KJ3FC with KFC-1
24 810-2006
Valve, Ball – 2" [Nut (Handle Retainer) Included]
* 200-0487
Bracket, Support – Drain Valve
25 200-0512
Activator, Drain Valve Microswitch
26 812-1462
Handle, Drain Valve – Universal
* Not Illustrated
Use standard part.
