9-8
P codes: Motor Parameters
Code Name Data setting range
Incre-
ment
Unit
Change
when
running
Data
copy
Default
setting
Refer
to:
P02
Motor Parameters
(Rated capacity)
0.01 to 10.00 kW (where, the data of function
code P99 is 0, 3, or 4.)
0.01 to 10.00 HP (where, the data of function
code P99 is 1.)
0.01
0.01
kW
HP
N Y1
Y2
Nominal
*
2
rated
capacity o
Fuji
standard
motor
P03
(Rated current)
0.00 to 99.99 0.01 A N Y1
Y2
Nominal
*
2
rated
current of
Fuji
standard
motor
P09
(Slip compensation
gain)
0.0 to 200.0
Typical rated slip frequency
at 100%
0.1 % Y* Y 0.0
9-49
P99
Motor Selection
0: Characteristics of motor 0
(Fuji standard 8-series motors)
1: Characteristics of motor 1 (HP motors)
3: Characteristics of motor 3
(Fuji standard 6-series motors)
4: Other motors
—— N Y1
Y2
1 9-50
H codes: High Performance Functions
Code Name Data setting range
Incre-
ment
Unit
Change
when
running
Data
copy
Default
setting
Refer
to:
H03 Data Initialization
(Data reset)
0: Disable initialization
1: Initialize all function code data to the factory
defaults
2: Initialize motor parameters
— — N N 0 9-51
H04 Retry
(No. of retries)
0: Disable
1 to 10
1
Times
Y Y 0
H05 (Latency time) 0.5 to 20.0 0.1 s Y Y 5.0
9-54
H06 Cooling Fan ON/OFF 0: Disable
1: Enable (2 HP or more)
— — Y Y 0 9-55
H07 Gradual Acceleration/
Deceleration
0: Disable (Linear)
1: S-curve (Weak)
2: S-curve (Strong)
3: Curvilinear
— — Y Y 0 9-56
H12 Instantaneous
Overcurrent Limiting
0: Disable
1: Enable
— — Y Y 1 9-57
H26 PTC Thermistor Input 0: Disable
1: Enable (PTC)
— — Y Y 0
H27 (Level) 0.00 to 5.00 0.01 V Y Y 1.60
9-57
H30 Communications Link
(Function selection)
Monitor Frequency Run command
command source source
0: Y N N
1: Y RS-485 N
2: Y N RS-485
3: Y RS-485 RS-485
Y: Enable by inverter and via RS-485
communication (option)
RS-485: Enable via RS-485 communication
(option)
N: Enable by inverter
— — Y Y 0 9-59
H42 Capacity of DC link bus
capacitor
For adjustment when replacing the capacitor — — — N — 9-59
H43 Accumulated Run
Time of Cooling Fan
For adjustment when replacing the cooling fan — — — N — 9-59
* "Fuji's standard torque boost," "Nominal rated current of Fuji standard motor," and "Nominal rated capacity of Fuji standard motor" differ
depending upon the rated input voltage and rated capacity. Refer to Table 9.1 "Fuji Standard Motor Parameters" on page 9-11.
