9.1 Function Code Tables
9-7
Chap. 9 FUNCTION CODES
C codes: Control Functions of Frequency
Code Name Data setting range
Incre-
ment
Unit
Change
when
running
Data
copy
Default
setting
Refer
to:
C01
Jump Frequency 1
0.0 to 400.0 0.1 Hz Y Y 0.0
C02
2
Y 0.0
C03
3
Y 0.0
9-46
C04
Jump Frequency Band
0.0 to 30.0 0.1 Hz Y Y 3.0 9-46
C05
Multistep Frequency
Settings 1
0.00 to 400.00 0.01 Hz Y Y 0.00
C06
2
Y 0.00
C07
3
Y 0.00
C08
4
Y 0.00
C09
5
Y 0.00
C10
6
Y 0.00
C11
7
Y 0.00
9-46
C20
Jogging Frequency
0.00 to 400.00 0.01 Hz Y Y 0.00 9-47
C21
Timer Operation
0: Disable timer operation
1: Enable timer operation
— — N Y 0 9-47
C30
Frequency Command 2
0: Enable
and keys on the built-in
keypad
1: Enable the voltage input to terminal [12]
2: Enable the current input to terminal [C1]
3: Enable the sum of voltage and current inputs
to terminals [12] and [C1]
4: Enable the built-in potentiometer (POT)
— — N Y 2 9-12
9-48
C32
Analog Input
Adjustment
(Gain for terminal input
[12])
(Gain)
0.00 to 200.00 0.01 % Y* Y 100.0 9-22
9-48
C33
(Filter)
0.00 to 5.00 0.01 s Y Y 0.05 9-48
C34
(Gain reference point)
0.00 to 100.00 0.01 % Y* Y 100.0 9-22
9-48
C37
Analog Input
Adjustment
(Gain for terminal input
[C1])
(Gain)
0.00 to 200.00 0.01 % Y* Y 100.0 9-22
9-48
C38
(Filter)
0.00 to 5.00 0.01 s Y Y 0.05 9-48
C39
(Gain reference point)
0.00 to 100.00 0.01 % Y* Y 100.0 9-22
9-48
C50
Bias
(
Frequency
command 1
)
(Bias reference point)
0.00 to 100.00 0.01 % Y* Y 0.00 9-22
9-48
C51
Bias (PID command 1)
(Bias value)
-100.00 to 100.00 0.01 % Y* Y 0.00 9-48
C52
(Bias reference point)
0.00 to 100.00 0.01 % Y* Y 0.00 9-48
