Fuji Electric frenic mini series - Page 191

9-6
Code Name Data setting range
Incre-
ment
Unit
Change
when
running
Data
copy
Default
setting
Refer
to:
E50
Coefficient for Speed
Indication
0.01 to 200.00 0.01 —
Y Y
30.00
9-43
9-44
E52
Menu Display Mode
for Keypad
0: Function code data setting mode
1: Function code data check mode
2: Full-menu mode
——
Y Y
0
9-44
E60
Built-in Potentiometer
(Function selection)
0: None
1: Auxiliary frequency command 1
2: Auxiliary frequency command 2
3: PID process command 1
—— N
Y
0
9-44
E61
Analog Input Signal
Definition for: [12]
—— N
Y
0
9-44
E62
[C1]
0: None
1: Auxiliary frequency command 1
2: Auxiliary frequency command 2
3: PID process command 1
5: PID feedback value
—— N
Y
0
9-44
E98
Terminal Command
Assignment to: [FWD]
—— N
Y
98
E99
[REV]
To assign a negative logic input to a terminal, set
the value of 1000s shown in ( ) in the table below
to the function code.
0: (1000) Select multistep frequency
(0 to 1 steps) (SS1)
1: (1001) Select multistep frequency
(0 to 3 steps) (SS2)
2: (1002) Select multistep frequency
(0 to 7 steps) (SS4)
4: (1004) Select ACC/DEC time
(2 steps) (RT1)
6: (1006) Enable 3-wire operation
(HLD)
7: (1007) Coast to a stop (BX)
8: (1008) Reset alarm (RST)
9: (1009) Enable external alarm trip (THR)
10: (1010) Ready for jogging (JOG)
11: (1011) Switch set frequency 2/1
(Hz2/Hz1)
19: (1019) Enable write from keypad (WE-KP)
20: (1020) Cancel PID control (Hz/PID)
21: (1021) Switch normal/inverse operation
(IVS)
24: (1024) Enable communications link
(RS-485 communication, option) (LE)
33: (1033) Reset PID integral and differential
components (PID-RST)
34: (1034) Hold PID integral component
(PID-HLD)
98: Run forward (FWD)
99: Run reverse (REV)
—— N
Y
99
9-33
9-45
