9.2 Details of Function Codes
9-53
Chap. 9 FUNCTION CODES
If P99 (Motor selection) is set to 1 (HP motors):
Rated current (A)
If P99(Motor selection) is set to:
Setting
range
(HP)
1
Shipping destination (Version)
Power
supply
voltage
Function
code
P02
Appli-
cable
motor
rating
(HP)
Asia EU Japan
0.01 to 0.10 0.1 0.44 0.44 0.44
0.11 to 0.12 0.12 0.68 0.68 0.68
0.13 to 0.25 0.25 1.40 1.40 1.40
0.26 to 0.50 0.5 2.00 2.00 2.00
0.51 to 1.00 1 3.00 3.00 3.00
1.01 to 2.00 2 5.80 5.80 5.80
2.01 to 3.00 3 7.90 7.90 7.90
3.01 to 5.00 5 12.60 12.60 12.60
5.01 to 7.50 7.5 18.60 18.60 18.60
Three-phase 230V
Single-phase 230V
7.51 to 10.00 10 25.30 25.30 25.30
0.01 to 0.10 0.1 0.22 0.22 0.22
0.11 to 0.12 0.12 0.34 0.34 0.34
0.13 to 0.25 0.25 0.70 0.70 0.70
0.26 to 0.50 0.5 1.00 1.00 1.00
0.51 to 1.00 1 1.50 1.50 1.50
1.01 to 2.00 2 2.90 2.90 2.90
2.01 to 3.00 3 4.00 4.00 4.00
3.01 to 5.00 5 6.30 6.30 6.30
5.01 to 7.50 7.5 9.30 9.30 9.30
Three-phase 460V
7.51 to 10.00 10 12.70 12.70 12.70
NOTE: The above values in the "Rated current" column are exclusively applicable to the four-pole Fuji standard motors rated for 230 V
and 460 V at 60 Hz. If you use non-standard or other manufacturer’s motors, change the P02 data to the rated current printed on the
motor's nameplate.
