A-32
FVR-C11S vs. FRENIC-Mini
Function
code
Name
Function
code
Name
F00 Data protection F00 Data Protection
F01 Frequency command F01 Frequency Command Source 1
F02 Operation method F02 RUN Command Source
F03 Maximum frequency F03 Maximum Frequency
F04 Base frequency F04 Base Frequency
F07 Acceleration time F07 Acceleration Time 1
F08 Deceleration time F08 Deceleration Time 1
F09 Torque boost F09 Torque Boost The data implements other function.
For details, refer to the torque boost setting
conversion table on page A-33.
F37 Load Selection/Auto Torque
Boost/Auto Energy Saving Operation
Select the reduced/constant torque using F37.
F10 Electronic thermal overload relay
(Select)
F10 Electronic Thermal Motor Overload
Protection (Select motor
characteristics)
Select "Disable" using F11 (= 0.00) instead of
F10.
F11 Electronic thermal overload relay
(Level)
F11 Electronic Thermal Motor Overload
Protection (Overload detection
current)
F12 Electronic thermal overload relay F12 Electronic Thermal Motor Overload
Protection (Thermal time constant)
F14 Restart mode after momentary
power failure (Select)
F14 Restart after Instantaneous Power
Failure
Replace the data of FVR-C11S from 2 to 4 of
FRENIC-Mini and from 3 to 5.
F15 Frequency limiter (Peak) F15 Frequency Limiter (High)
F16 Frequency limiter (Bottom) F16 Frequency Limiter (Low)
F17 Gain (Frequency setting) C32 Analog Input Adjustment (Gain for
terminal input [12]) (Gain)
C34 Analog Input Adjustment (Gain for
terminal input [12]) (Gain reference
point)
F18 Bias frequency F18 Bias (for Frequency Command 1,
F01)
C50 Bias (Frequency command 1)
(Bias reference point)
F20 DC brake (Starting freq.) F20 DC Braking (Start frequency) Set at 3 Hz.
F21 DC brake (Braking level) F21 DC Braking (Braking level)
F22 DC brake (Braking time) F22 DC Braking (Braking time)
F23 Starting frequency F23 Start Frequency
F25 Stop frequency F25 Stop Frequency
F26 Motor sound (Carrier freq.) F26 Motor Sound (Carrier frequency)
F27 Motor sound (Sound tone) F27 Motor Sound (Sound tone)
F30 FM terminal (Voltage adjustment) F30 Terminal [FMA] (Gain to output
voltage)
F31 FM terminal (Select) F31 Terminal [FMA] (Monitor object) The selection for the data differs each other. For
details refer to Chapter 9 "FUNCTION CODES."
F36 30Ry operation mode E27 [30A/B/C] Terminal Function
(Mechanical relay contacts)
If F36=0, set E27=99, if F36=1, set E27=1099.
E01 X1 terminal function (Select) E01 X1 Terminal Function
E02 X2 terminal function (Select) E02 X2 Terminal Function
E03 X3 terminal function (Select) E03 X3 Terminal Function
C01 Jump frequency 1 C01 Jump Frequency 1
C02 Jump frequency 2 C02 Jump Frequency 2
C03 Jump frequency 3 C03 Jump Frequency 3
C04 Jump frequency (Hysteresis) C04 Jump Frequency Band
C05 Multistep frequency setting 1 C05 Multistep Frequency Settings 1
C06 Multistep frequency setting 2 C06 Multistep Frequency Settings 2
C07 Multistep frequency setting 3 C07 Multistep Frequency Settings 3
P00 Motor Characteristics No function code with same feature. No setting
required.
H01 Operation time Check the alarm information from the keypad.
Refer to Chapter 3 for details.
H02 Trip history Check the alarm information from the keypad.
Refer to Chapter 3 for details.
H03 Data initializing H03 Data Initialization (Data reset)
H04 Auto-reset (Times) H04 Retry (No. of retries) If the retry is disabled, set 0. If enabled, set
5times.
H05 Retry (Latency time)
Remarks
The selection for the data differs each other. For
details refer to Chapter 9 "FUNCTION CODES."
Analog input is applied to [12] so that the gain
for set frequency is equal to the gain for [12].
Setting differs each other. Refer to Chapter 9
"FUNCTION CODES" for details.
