App. G Replacement Information
A-33
App.
Function
code
Name
Function
code
Name
H06 Fan stop operation H06 Cooling Fan ON/OFF
H20 PID control (Select) J01 PID Control
H21 PID control
(Feedback signal select)
E61 Terminal [12] (Function selection) To select the [12] as the feedback set the data of
5.
E62 Terminal [C1](Function selection) To select the [C1] as the feedback set the data of
5.
C32 Analog Input Adjustment (Gain for
terminal input [12]) (Gain)
When the frequency is commanded in 1-5V,
select the [12] and set the C32 (analog input
gain) for 200%. Use it as 0-5V range.
H22 PID control P (gain) J03 PID control P (gain)
H23 PID control I (Integration time) J04 PID control I (Integration time)
H24 PID control D (Differentiation time) J05 PID control D (Differentiation time)
H25 PID control (Feedback filter) J06 PID control (Feedback filter)
o00 Option select (RS-485) y10 RS-485 (Protocol selection) Select 2 (Fuji general-purpose protocol).
o01 Station address y01 RS-485 (Station address)
o02 Mode select on no response error y02 RS-485
(Mode selection on no response
error)
o03 Timer y03 RS-485 (Timer)
o04 Baud rate y04 RS-485 (Transmission speed) 1200 bps is not supported.
o05 Data length y05 RS-485 (Data length)
o06 Parity check y06 RS-485 (Parity check)
o07 Stop bits y07 RS-485 (Stop bits)
o08 No response error detection time y08 RS-485
(No response error detection time)
o09 Response interval y09 RS-485 (Response interval)
o10 RS-485 command select
(Frequency setting)
H30 Communications Link
(Function selection)
o11 RS-485 command select
(Running command)
For details of the data compatibility, refer to
Chapter 9 "FUNCTION CODES."
Remarks
FVR-C11S FRENIC-Mini
Conversion Table for Setting Torque Boost
Inverter
Series Name
FVR-C9S
FVR-C11S
Func. Codes F09 F09 F37
00 0
1
20 1
30.2 1
40.8 1
51.5 1
62.3 1
73.1 1
83.9 1
94.7 1
10 5.5 1
11 6.3 1
12 7.2 1
13 8 1
14 8.9 1
15 9.8 1
16 10.6 1
17 11.5 1
18 12.5 1
19 13.2 1
20 14.1 1
21 15 1
22 15.8 1
23 16.7 1
24 17.5 1
25 18.3 1
26 19.2 1
27 20 1
28 20 1
29 20 1
30 20 1
31 20 1
None, Consult us.
FRENIC-Mini
Data
