QD002-07 3. Machine Set Up
NXT Setup Manual 113
3.8.13 Fastening Extensions
All individual bases are connected together for base extensions.
Connection of Bases at the Front
DWG. No. Description Qty.
PM39012 Bracket 2
PM39021 Bracket 1
PM39031 Bracket 1
PM39040 Bolt 1
NXTSET018
