1. Safety Guideline QD002-07
6 NXT Setup Manual
1.3 Safety Rules for NXT
1.3.1 Main Unit
WARNING
Do not insert hands or other body parts into the machine in the
area between feeders especially when there are only a few
feeders present on the feeder pallet.
• Failure to do so could result in injury due to contact with the body
part and the head during movement.
When changing the conveyor width with the module retracted,
do not insert hands in the area near the conveyor
• Fingers may be pinced or caught in the movable conveyor rail,
resulting in serious injury.
When mounting the MCU, ensure that no one is between the
MCU and machine base
• A person could be crushed to death if caught between the MCU and
base.
When pushing a module onto the base, check that no one is
behind the module
• A person could be crushed between the base and module, resulting
in serious injury.
When pushing in a module, do not insert hands between the
module cover support and module
• Fingers may be pinced or caught, resulting in serious injury.
When pushing in a module, do not insert hands between the
module lower front cover and base
• Fingers may be pinced or caught, resulting in serious injury.
When pulling out or pushing in a module, do not insert hands or
other body parts in between modules
• If caught between modules, fingers or other body parts could be cut
or severed.
When working on the module in an opening with the cover off,
ensure that no one pushes or pulls out in the module
• The module may punch, sever, or cause serious injury.
