QD002-07 3. Machine Set Up
NXT Setup Manual 33
3.4 Making Basic Connections
The procedures for connecting the three basic connections; power, network, and air are
described below. It should be the easiest to connect these three connections at the same
time.
3.4.1 Electric power supply
Power supply of 200 - 230 VAC is required. An external transformer is required when the
power supply voltage lies outside this range.
The maximum power capacity is 6.5 kVA. Be sure to connect the machine to a power
supply which exceeds this capacity.
The factory power supply should be equipped with a ground leakage breaker meeting the
following requirements for safety.
• Rated current: 100 [mA]
• Actuation time: 0.1 sec or less (high speed)
Procedure
1. Remove the waste tape boxes and then remove the cover underneath the power
switch.
2. Feed the power cable from the bottom of the base.
DANGER
Verify that the external power supply is OFF before performing this
procedure and that no power is being supplied to the cable.
To Next Page
