FujiFilm NXT - Machine Set Up; Moving a Machine

QD002-07 3. Machine Set Up
NXT Setup Manual 23
3. Machine Set Up
The procedures in this chapter are used to set up a machine that is newly arrived or that
has been moved to a new location. Not all sections are not required in all cases, just
perform the actions necessary.
3.1 Moving a Machine
Use a forklift or similar lifting device to move the machine to the setup location. Place
leveling sheets on the floor and lower the machine onto the leveling sheets. Furthermore,
depending on the machine base configuration, it may be necessary to secure the base to
the floor using anchor bolts or adhesive sheets and so forth to prevent the bases from
shifting.
3.1.1 Precautions when moving the machine
When moving a machine, be sure to observe the safety measures described below in
order to avoid accidents.
• Be sure that the workers who are moving the machine are wearing safety
shoes and helmets.
• Prepare the transport path in advance, and be sure that those who are not
assisting in the machine transport are kept out of the area.
• The machine should be moved only by qualified personnel.
• Before moving the machine, attach the machine brackets (red) which were
attached when the machine was delivered. (Attach the brackets in the
prescribed positions.)
Machine Weight
Weights for each type of module, base, and tray unit used in the NXT are listed below.
The actual weight of the machine should be calculated based on the type of module(s),
base and tray-unit(s) being used. (Values listed below do not include the weight of any
packing materials.)
Note:
1.Use a forklift which is suitable for the weight of the machine in question.
2.Be sure to insert the forklift forks at the prescribed position.
3.Use care to avoid bending the leveling bolts.
4.If the balance of a lifted machine is unstable, lower the machine immediately.
5.Raise and lower the machine slowly to avoid subjecting the machine to shocks.
NXT Description Weight (kg)
2M base 345kg
Stand-alone control box for 2M
base
123kg
Indipendent 4M base 720kg
Dependent 4M base 680kg
