Chapter 4 Connectivity Management
4.3 CA Port Group Management
ETERNUS Web GUI User’s Guide (Settings)
Copyright 2015 FUJITSU LIMITED P2X0-1270-13ENZ0
433
The main setting items are as follows.
● CA Port Group Setting
• Name
• Checkbox to select ports
3 Click the [Create] button.
A confirmation screen appears.
4 Click the [OK] button.
Registration of the iSCSI port group starts.
5 Click the [Done] button to return to the [CA Port Group] screen.
4.3.3 Create SAS Port Group
This function creates a new SAS port group, and registers the port to be a member.
A SAS port group is a group of SAS-CA type ports that are connected to the specified host group. The Host
Affinity is specified for each SAS port group.
If an error screen appears under the following conditions, check the parameter settings.
• The "Name" is not entered
• The "Name" does not satisfy the input conditions
• The "Name" overlaps with an existing port group name
(port group names cannot overlap with any other port group names, irrespective of the CA types.)
• The total number of port groups has exceeded the maximum number for the ETERNUS DX
• Nine or more ports are registered in the port group or no ports are registered in the port group
• Ports with the affinity mode enabled (On) and disabled (Off) exist together
To Next Page
