Page #12 background image
1. ETERNUS AX/HX Installation
Installation Specifications
Site Planning Guide12
*1: A 2U power distribution unit is composed of two 1U power distribution units.
*2: These values are for each shelf when 24 drives are installed.
*3: The value in the parentheses for the controller shelf and drive shelves includes the mass of the rack rail kit.
*4: These values are for the maximum load when all the available options are installed in an ETERNUS AX/HX.
*5: The operating test was performed in environments compatible with the Operating Condition Class A2 of the EU eco-
design directive (ErP Directive 2009/125/EC).
Maximum power
consumption (*2)
Controller
shelf
2.5" type AC100 – 120V 1,580 W (1,630 VA)
AC200 – 240V 1,528 W (1,560 VA)
Drive
shelf
DS224C
2.5" type
AC100 – 120V 390 W (398 VA)
AC200 – 240V 383 W (392 VA)
NS224 AC100 – 120V 848 W (848 VA)
AC200 – 240V 810 W (810 VA)
Maximum configuration
(*4)
AC100 – 120V 9,380 W (9,590 VA)
AC200 – 240V 9,188 W (9,400 VA)
Maximum heat
generation (*2)
Controller
shelf
2.5" type AC100 – 120V 5,688 kJ/h
AC200 – 240V 5,501 kJ/h
Drive
shelf
DS224C
2.5" type
AC100 – 120V 1,404 kJ/h
AC200 – 240V 1,379 kJ/h
NS224 AC100 – 120V 3,053 kJ/h
AC200 – 240V 2,916 kJ/h
Maximum configuration
(*4)
AC100 – 120V 33,768 kJ/h
AC200 – 240V 33,077 kJ/h
Maximum amount of
exhaust air
Controller shelf -
Drive
shelf
2.5" type / 3.5" type -
60-drive type -
Environmental
conditions
Tempera-
ture
Operating (*5) 10 – 35 °C
Not operating -40 – 70 °C
During shipment -40 – 70 °C
Temperature gradient 15 °C/Hr or less
Humidity Operating (*5) 8 – 80 %RH
Not operating 10 – 95 %RH
During shipment 10 – 95 %RH
Humidity gradient 30 %/day or less
Maximum wet bulb temperature 29 °C
Altitude above sea level 0 – 3,048 m
Airborne dust
0.15 mg/m
3
or less
Gas concentration tolerance level Cl
2
: 6.8 ppb or less, H
2
S: 7.1 ppb or less,
SO
2
: 37 ppb or less, NH
3
: 423.5 ppb or less,
NO
2
: 52.3 ppb or less, O
3
: 5 ppb or less,
HCl: 6.6 ppb or less, HF: 3.6 ppb or less
Oil vapor
0.2 mg/m
3
or less
Seawater (salt corrosion) If the ETERNUS AX/HX is installed on the ocean or
premises within 0.5 km from the coast, necessary
measures must be taken to prevent salt corrosion.
Noise emission (*6) Sound pressure level 67.2 dBA
Sound power level 8.5 B
Item ETERNUS AX4100
