Site Planning Guide9
1. ETERNUS AX/HX Installation
This chapter provides the installation specification of the ETERNUS AX/HX.
Installation Specifications
• ETERNUS AX series All-Flash Arrays
- "ETERNUS AX1100/AX2100/AX2200" (page 9)
- "ETERNUS AX4100" (page 11)
• ETERNUS HX series Hybrid Arrays
- "ETERNUS HX2100/HX2200" (page 13)
- "ETERNUS HX6100" (page 16)
ETERNUS AX1100/AX2100/AX2200
Each installation specification is shown below.
• Installation specifications: Table 1
• Sound level of the drive shelf: Table 2
• Efficiency and the power factor of the power supply unit: Table 3
Table 1 Installation Specifications (ETERNUS AX1100/AX2100/AX2200)
Item
ETERNUS
AX1100
ETERNUS
AX2100
ETERNUS
AX2200
Dimensions
(W × D × H)
2.5" type controller shelf 480 × 483 × 85
mm (2U)
480 × 483 × 85
mm (2U)
483 × 543 × 87
mm (2U)
DS224C 2.5" type drive shelf - 480 × 484 × 85
mm (2U)
-
NS224 drive shelf - - 483 × 543 × 87
mm
Power distribution unit (2U) (*1) (485 × 123 × 44 mm) × 2
Maximum
weight (*2)
(*3)
2.5" type controller shelf 27.6 kg
(31.6 kg)
27.6 kg
(31.6 kg)
24.6 kg
(28.6 kg)
DS224C 2.5" type drive shelf - 24.4 kg
(28.4 kg)
-
NS224 drive shelf - - 30.3 kg
(34.3 kg)
Power distribution unit (2U) (*1) (3.0 kg) × 2
Power Voltage AC 100 – 120V, AC 200 – 240V
Phase Single
Frequency 50 Hz / 60 Hz
