1. ETERNUS AX/HX Installation

Rack Dimensions

Site Planning Guide23

Rack Dimensions

The following diagrams show the dimensions of a 19-inch rack and an anti-tipping stabilizer.

The dimensions are approximations and do not include protruding parts.

For specification information that is required for securing a rack, refer to Figure 14

under "Installation Methods"

(page 31).

Figure 9 19-inch Rack Dimensions

Top

Front RearSide

Bottom

2,000 mm

1,050 mm

700 mm
