1. ETERNUS AX/HX Installation
Installation Specifications
Site Planning Guide11
*2: These values are for each shelf when 24 drives are installed.
*3: The value in the parentheses for the controller shelf and drive shelves includes the mass of the rack rail kit.
*4: These values are for the maximum load when all the available options are installed in an ETERNUS AX/HX.
*5: The operating test was performed in environments compatible with the Operating Condition Class A4 of the EU eco-
design directive (ErP Directive 2009/125/EC).
*6: The operating test was performed in environments compatible with the Operating Condition Class A2 of the EU eco-
design directive (ErP Directive 2009/125/EC).
*7: For details about the sound level of the drive shelf, refer to "Table 2 Sound Level of the Drive Shelf" (page 11)
.
Table 2 Sound Level of the Drive Shelf
Table 3 Efficiency and Power Factor of the Power Supply Unit
*1: Indicates the rated load against the rated output of the PSU.
ETERNUS AX4100
Each installation specification is shown below.
• Installation specifications: Table 4
• Sound level of the drive shelf: Table 5
• Efficiency and the power factor of the power supply unit: Table 6
Table 4 Installation Specifications (ETERNUS AX4100)
DS224C NS224
Sound pressure level 51 dBA 49.8 dBA
Sound power level 6.9 B 6.4 B
Component name
80PLUS®
Efficiency Power factor
Output
Shelf 20 % (*1) 50 % (*1) 100 % (*1) 50 % (*1)
ETERNUS AX1100 Platinum 91.8 % 94.2 % 92.7 % 0.980 Multiple output
ETERNUS AX2100 91.8 % 94.2 % 92.7 % 0.980
ETERNUS AX2200 93.5 % 94.2 % 91.4 % 1.000 Single output
DS224C drive shelf 91.8 % 94.2 % 92.7 % 0.980 Multiple output
NS224 drive shelf 93.5 % 94.2 % 91.4 % 1.000 Single output
Item ETERNUS AX4100
Dimensions
(W × D × H)
2.5" type controller shelf 483 × 828 × 175 mm (4U)
DS224C 2.5" type drive shelf 480 × 484 × 85 mm (2U)
NS224 drive shelf 483 × 543 × 87 mm (2U)
Power distribution unit (2U) (*1) (485 × 123 × 44 mm) × 2
Maximum weight (*2)
(*3)
2.5" type controller shelf 49.9 kg (53.9 kg)
DS224C 2.5" type drive shelf 24.4 kg (28.4 kg)
NS224 drive shelf 30.3 kg (34.3 kg)
Power distribution unit (2U) (*1) (3.0 kg) × 2
Power Voltage AC 100 – 120V, AC 200 – 240V
Phase Single
Frequency 50 Hz / 60 Hz
