1. ETERNUS AX/HX Installation
Installation Specifications
Site Planning Guide18
19-inch Racks
The following table shows the installation specifications of the 19-inch racks.
Table 13 19-inch Rack Installation Specifications
Table 14 19-inch Wide Rack Installation Specifications
Item
Specification
Base rack Expansion rack
Dimensions (W × D × H) 700 × 1,050 × 2,000 mm
700 × 1,272 × 2,000 mm (including anti-tipping stabilizer)
Maximum weight 129 kg 103 kg
Service area Refer to Figure 12
under "Installation Area" (page 28).
Number of units 42U
Item
Specification
Base rack Expansion rack
Dimensions (W × D × H) 800 × 1,200 × 2,000 mm
800 × 1,432 × 2,000 mm (including anti-tipping stabilizer)
Maximum weight 155 kg 125 kg
Service area (including a space for
using the lifter)
Refer to Figure 13
under "Installation Area" (page 28).
Number of units 42U
