2. Rack Installation Specifications
Installable Racks
Site Planning Guide64
Installable Racks
This section explains the racks in which the ETERNUS AX/HX can be installed.
Fujitsu Racks
The ETERNUS AX/HX can be installed in a Fujitsu 19-inch rack. For information about whether the ETERNUS AX/HX
can be installed in an EOLed rack or not, contact your sales representative.
Table 29 Installable Racks
*1: Because the depth is larger, the DS460C drive shelf can only be installed in 19-inch wide racks.
■ Precautions for Installing a DS460C Drive Shelf in a Rack
• Because the depth is larger than other shelves, install the shelf in a 19-inch rack designated by Fujitsu or a
rack with a rack space of 922 mm (external depth of the drive shelf) plus an additional 100 mm or more cable
area.
• Refer to "Non-Fujitsu Racks" (page 65)
for the specification of the rack space in a rack.
Model Rack
• Controller shelf
- ETERNUS AX1100/AX2100/AX2200/AX4100
- ETERNUS HX2100/HX2200/HX6100
19-inch rack
• Drive shelf
- DS212C
- DS224C
- NS224
• Controller shelf
- ETERNUS AX1100/AX2100/AX2200/AX4100
- ETERNUS HX2100/HX2200/HX6100
19-inch wide rack
• Drive shelf
- DS212C
- DS224C
- DS460C (*1)
- NS224
