1. ETERNUS AX/HX Installation
Outlet/Socket Specifications
Site Planning Guide37
■ Power Distribution Unit (AC24A/200V, 2U, Six Outlets)
There are six outlets and two inlets.
Estimate the maximum current consumption to supply power to all the connected devices using one of the mod-
ules of the power distribution unit.
This is supported in the ETERNUS HX series only.
Figure 17 Power Distribution Unit (AC24A/200V, 2U, Six Outlets)
Table 23 Specifications for Power Distribution Units (AC24A/200-240V, 2U, Six Outlets)
Table 24 Specifications for Power Distribution Units (AC24A/200-240V, 2U, Six Outlets) (for Korea)
Outlet Inlet
Voltage rating/current rating
Socket type
(Socket)
Plug type
Socket type
(Socket)
Power cord
length
IEC60320 C19 NEMA L6-30P NEMA L6-30R 4.4m Rating: 200-240V 24A
Outlet Inlet
Voltage rating/current rating
Socket type
(Socket)
Plug type
Socket type
(Socket)
Power cord
length
IEC60320 C19 IEC Industrial
Plug IP44 32A
2P+PE
IEC Industrial
Socket IP44 32A
2P+PE
4.4m Rating: 200-240V 24A
Six outlets
Two inlets
